Chapter 12 VLAN
MES-2110 User’s Guide
108
12.5.8 The Tag-Based Port Configuration Screen
Use this screen to configure the VLAN group settings for each port on the MES-2110.
Click Configuration > VLAN Menu > Tag-Based > Tag-Based info. to open
the following screen.
Figure 44 Configuration > VLAN Menu > Tag-Based > Tag-Based info.
The following table describes the labels in this screen.
Undo Click this to restore your last saved settings.
Apply Click Apply to save your changes to the MES-2110’s run-time
memory. The MES-2110 loses these changes if it is turned off or
loses power, so use the Save Settings link in the navigation
panel to save your changes to the non-volatile memory when you
are done configuring.
Table 35 Configuration > VLAN Menu > Tag-Based > Port Info.
LABEL DESCRIPTION
Table 36 Configuration > VLAN Menu > Tag-Based > Tag-Based info.
LABEL DESCRIPTION
VLAN ID Select whether you want to Add or Modify a VLAN ID.
Enter the VLAN ID from 1-4094 that you want to configure.
Priority This is the priority you want to assign to the tag-based VLAN.
