System components

Page 63 of 466

Communication Server 1000E

Installation and Commissioning

Power

Power status indicator (Nortel logo) is located on
the unit faceplate.

Power cord connector is located on the right rear
when viewed from the front.

Power On/Off switch is located behind the
faceplate. See Figure 10 on

page 66

.

Power supplies are factory installed and not
customer replaceable.

Unit is AC powered (100-240 VAC); DC is not
supported.

Cooling

Forced air cooling with side-to-side air flow.

The fans are temperature controlled. The fans run
at a reduced speed at room temperature.

Ensure that equipment ventilation openings are
not blocked.

Card slots

Four usable universal card slots: 1 to 4.

Slot 0 is dedicated to the NTDK20FA or later SSC.

Slots 1 to 4 support:

Digital Line cards (maximum four)

Analog Line cards (maximum four)

Analog Trunk cards (maximum four)

Digital Trunk cards (maximum four)

Media Cards (maximum four)

Application cards (maximum four)

Table 4
Media Gateway profile (Part 2 of 3)

Property

Description
