Page 268 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server
NN43041-310 Standard 01.11 October 2008
Configuring a Terminal Server
Follow Procedure 59 to connect a Terminal Server with a CS 1000E system.
Table 20 lists the MRV cables required to install the LX8020S-102AC-R
Terminal Server in a CS 1000E system.
Customer-made cables with the following pin out can also be used. See Table
21.
Table 20
Required MRV serial cables and connectors
Order Code Description
NTDU6302 Connects MRV Terminal Server to any standard
DTE port or DCE port when a Null modem is
used
NTDU6303 Used for telnet, rlogin connections
P/N-151-3028 Male RJ-45 to Male RJ-45 with connectors,
10 feet
P/N-350-0308 Female RJ-45 to Female DB9
Table 21
Customer made cable pin out (same as NTDU6302)
Pins on DB9 Female Pins on RJ-45 Male (MRV Terminal Server)
1
6 DCD
DSR 2 DTR
2 RXD 3 TxD
3 TXD 6 RxD
4 DTR 7 DSR/DCD
5 S GND 4
5 TxD GND
RxD GND
7 RTS 1 CTS
