Installing and configuring a Voice Gateway Media Card

NN43041-310

Standard 01.11

October 2008

Installing a CompactFlash

The Voice Gateway Media Card requires a CompactFlash card to operate.
The CompactFlash card contains the IP Line 3.1 software.

The Voice Gateway Media Card

package includes the following:

•

Media Card

•

CompactFlash card and Retaining Pin (nylon pillar)

•

Shielded 50-pin to Serial/ELAN/TLAN adapter

The CompactFlash card must be installed on the Voice Gateway Media Card
prior to installing the Voice Gateway Media Card in the system. Figure 133
on

shows the CompactFlash card location on the Voice Gateway

Media Card.

CAUTION WITH ESDS DEVICES

Wear an antistatic device to avoid damage to the Voice
Gateway Media Card.
