In figure 139 – Nortel Networks 1000E User Manual
Page 332
Page 332 of 466
Installing and configuring a Voice Gateway Media Card
NN43041-310
Standard 01.11
October 2008
Press the Retaining Pin into the hole until the pin clicks as it locks into
position (labeled 2 in Figure 139). The underside of the head of the
Retaining Pin should be flat against the card.
Figure 139
Inserting the Retaining Pin
7
Turn the card over to view the front of the card. Ensure the Retaining Pin
is in place, as shown Figure 140 on
.
Figure 140
Retaining Pin fully inserted
End of Procedure
