Configuring the CS 1000E CP PM Call Server Page 163 of 466
Communication Server 1000E Installation and Commissioning
The type of any Bandwidth Management Zone for MG 1000E with
conference resources configured must be shared.
Distortion in Music is expected when G.729AB codec is used. Hence the
Interzone and the Intrazone policies for an MG 1000E Bandwidth
Management Zone should have Best Quality to give preference to G711
codec to minimize of occurrence of music distortion.
Ensure that the bandwidth provisioned is adequate to provide the acceptable
blocking level of the resources in the MG 1000E. Refer to the
Communication Server 1000E: Planning and Engineering (NN43041-220)
for details.
Configuring the MG 1000E ports
IP addresses must be configured on the CP PM Call Server for each
MG 1000E in the system. Use LD 97 to configure the MG 1000E ports.
IMPORTANT!
Currently, the CS 1000E only supports Recorded Announcement
Broadcast and Music Broadcast.
LD 97 – Configuring the MG 1000E ports
Prompt Response Comment
REQ CHG Change existing data
TYPE SUPL Superloop
SUPL Superloop for gateway
SLOT Default
SUPT IPMG MG 1000E
IPRO xx.xx.xx.xx IP address of for Media Gateway
ZONE0 x Zone for Media Gateway
