Installing a card in a media gateway – Nortel Networks 1000E User Manual
Page 333
Installing and configuring a Voice Gateway Media Card
Page 333 of 466
Communication Server 1000E
Installation and Commissioning
Installing a card in a Media Gateway
A Voice Gateway Media Card can be installed in a Media Gateway or a
Media Gateway Expander slot. See Figure 141 on
and Figure 142
to make sure that you insert the Voice Gateway Media Card in
the correct slot.
Note: See your installation worksheet, provided by your Planning and
Engineering group for the correct slot for the Voice Gateway Media
Cards.
Figure 141 shows the circuit card assignments in the Media Gateway.
Figure 141
Media Gateway card slot location
shows the circuit card assignments in the Media
Gateway Expander.
SLOT
0
SSC
SLOT
1
SLOT
2
SLOT
3
SLOT
4
Slot 4
Slot 3
Slot 2
Slot 1
Slot 0 - SSC
553-CSE9025
