Page 254 of 466 Connecting an IR-8020M-101 Terminal Server
NN43041-310 Standard 01.11 October 2008
Customer-made cables with the following pin out (as NTDU6302) can also
be used. See Table 17.
Procedure 52
Connecting a Terminal Server to the system
1 Connect the MRV P/N-151-3028 serial cable from the Terminal Server
console port 20 to the PC COM port.
2 Plug MRV PC Card (in MRV package) into Terminal Server faceplate
socket, and power on the Terminal Server.
3 Start the MRV HyperTerminal application. In Windows:
Start > Programs > Accessories > Communication >
HyperTerminal.exe
Table 17
Customer made cable pin out
Pins on DB9 Female Pins on RJ45 Male (MRV Terminal Server)
1
6 DCD
DSR 2 DTR
2 RXD 3 TxD
3 TXD 6 RxD
4 DTR 7 DSR/DCD
5 S GND 4
5 TxD GND
RxD GND
7 RTS 1 CTS
8 CTS 8 RTS
9 N/C
WARNING
Port 20 is the default console port. Do not change the
configuration for port 20.
