Installation
3-14
6710 Access Point User’s Guide
1
2
Figure 3-9
N-Series Transceiver
1. Drop cable
2 15-pin AUI port
3. N-Series transceiver
4. 10BASE5 coax
4
10 BASE 2
10 BASE T
AC INPUT
100/240 VAC
AUI
DIAG
3
