APPENDIX E
"
OWL/IP
E-20
6710 Access Point User’s Guide
Figure E-4
Example Class B Configuration
AP 1
(Super Root)
172.16.16.101
172.16.8.1
IP Router
Server for
IP Stations
172.16.23.141
172.16.16.1
Home Subnet
Server for
NNL Stations
AP 2
172.16.19.36
172.16.8.2
IP Router
172.16.32.1
AP 12
172.16.32.3
AP 11
172.16.32.2
AP 13
172.16.32.4
172.16.8.3
IP Router
172.16.40.1
AP 22
172.16.40.3
AP 21
172.16.40.2
AP 23
172.16.40.4
172.16.8.4
IP Router
172.16.48.1
AP 32
172.16.48.3
AP 31
172.16.48.2
AP 33
172.16.48.4
