APPENDIX F
"
Port and Cable Pin-Outs
6710 Access Point User’s Guide F-3
DIAG Port Cable
DIAG Port
to 9-pin Male PC Port
(Standard Null Modem Cable)
Part Number: 226-106-001 (6 feet)
2
PC
9-pin, D-sub
Female
Pin 6
Pin 1
Pin 9
Pin 5
Pin 6
Pin 1
Pin 5
Pin 9
6710
9-pin, D-sub
Female
3
3
4
5
6
8
2
1
6
5
4
8
F
6710
PC
SHELL GND
