APPENDIX G
"
MIB
G-46 6710 Access Point User’s Guide
ptxq OBJECT IDENTIFIER ::= { nInterfaces 5 }
ptxqTable OBJECT-TYPE
SYNTAX SEQUENCE OF PTXQEntry
ACCESS not-accessible
STATUS mandatory
DESCRIPTION
”The Port Transmit Queue Table”
::= { ptxq 1 }
ptxqEntry OBJECT-TYPE
SYNTAX PTXQEntry
ACCESS not-accessible
STATUS mandatory
INDEX { ptxqPort }
::= { ptxqTable 1 }
PTXQEntry ::=
SEQUENCE {
ptxqPort INTEGER,
ptxqRegQSize Gauge,
ptxqRegQMax INTEGER,
ptxqExpQSize Gauge,
ptxqExpQMax INTEGER,
ptxqQHpCount Counter,
ptxqQRegCount Counter,
ptxqQExpCount Counter,
ptxqQHpDiscards Counter,
ptxqQRegDiscards Counter,
ptxqQExpDiscards Counter,
ptxqMultiQSize Gauge,
ptxqMultiQMax INTEGER,
ptxqMultiQDiscards Counter
}
ptxqPort OBJECT-TYPE
SYNTAX INTEGER
ACCESS read-only
STATUS mandatory
DESCRIPTION
”MAC-R port ID (1-4).
A number which uniquely indentifies the port.”
::= { ptxqEntry 1 }
