SECTION 2
"
Features and Functional Overview
2-18 6710 Access Point User’s Guide
3. Rubber feet. Four nonskid rubber feet provide a
stable base for the access point when you place it on a
desktop or other horizontal surface.
When the mounting bracket is installed for an access
point mounted vertically or on the ceiling, the rubber
feet provide a small amount of tension to the bracket
to help hold it in place.
4. AC INPUT. The AC INPUT connector is a standard
IEC type, three-prong AC input connector. The power
cord attaches to this connector. The internal power
supply is an autosensing international power supply.
It accepts a source voltage between 85 and 264 V ac,
with a frequency between 47 and 63 Hz.
5. 10 BASE 2. The 10 BASE 2 port is a standard BNC
port through which the access point connects to
10BASE2 Ethernet (thinnet).
6. 10 BASE T. The 10 BASE T port is a standard RJ45
port through which the access point connects to
10BASE-T (UTP) Ethernet.
7. AUI. The AUI port is a 15-pin, D-subminiature
(D-sub) port. The access point connects to an AUI
network adaptor through this port, for connection to
10BASE5 Ethernet (thicknet). Appendix F, “Port and
Cable Pin-Outs,” contains pin definitions.
" NOTE: Section 3, “Installation,” shows how to connect the access point to
10BASE2, 10BASE5, and 10BASE-T.
8. DIAG. The DIAG port is a 9-pin D-sub
communication port that communicates at RS-232
levels. Use this port to configure the access point,
download new software, and retrieve statistics.
Appendix F contains pin definitions.
