APPENDIX D
"
S-UHF Specifications and Antennas
6710 Access Point User’s Guide D-5
# Frequencies # Wireless Stations
1 32
2 60
3 80
4 100
Installation Guidelines
The following pages contain guidelines for predicting the
coverage area and installing single and multiple access
points.
Predicting Coverage
Table D-1 shows predicted indoor coverage areas for an
access point with the S-UHF radio. The table was
generated using a mathematical mode. Areas are in square
meters. For square feet, multiply the area in square meters
by 10.
Table D-1
Coverage Prediction
Increased Coverage Overlap Between
Access Points
Ю Ю Ю
Increased obstructions 120K* 100K 80K 64K
ß 100K 84K** 64K** 51K
ß 82K 68K** 52K** 42K
ß 68K 56K 43K 34K*
* The extremes of 120K and 34K square meters are indicative
of best and worst case coverage results using this model.
** Reflects typical expected coverage for industrial and ware-
housing applications.
