SECTION 6
"
Indicator Lights
6710 Access Point User’s Guide 6-5
Table 6-3
MODE Indicator Light
Status Indication
ON Unit is not functional and is locked up.
BLINK Unit is in network mode, the normal operating
condition.
OFF Unit is in command mode. It enters this mode when
it detects a key press from an attached PC before it
enters the boot mode, or when it detects an incoming
signal from an attached modem.
NETWORK MODE Lights
NETWORK MODE indicator lights show the status of the
access point’s network link. The lights are labeled R-LINK
(left indicator) and W-LINK (right indicator). They work
together to indicate the type of network link the access
point has established. Table 6-4 shows links.
Table 6-4
NETWORK MODE Indicator Lights
R-LINK W-LINK Network Link Description
OFF
OFF No network link established (unit is not
connected to a network, or is reconfigur-
ing).
OFF ON Unit is attached to network through an
Ethernet port.
OFF BLINK Unit is attached to network through its
OWL/IP port and is the designated bridge
for a secondary Ethernet LAN.
ON OFF Unit is attached to the network through an
RF (radio) connection.
ON ON Unit is operating as the super root.
ON BLINK Unit is attached to network through an RF
connection and is the designated bridge for
a secondary Ethernet LAN.
