SECTION 4
"
Configuration
6710 Access Point User’s Guide 4-67
"
An Ethernet segment.
"
The radio range of a single access point with two
radios. One radio must be operating as a Master to
service wireless station traffic. The other radio must
be operating as a Slave to provide the wireless hop to
the distribution LAN.
" NOTE: You must set the Root Priority for the access point with the Slave
radio to 0 to prevent it from becoming the open wireless LAN super
root.
You must prevent the access point with the Slave radio
from synchronizing with Master radios in access points
attached to the same secondary LAN. To identify the
Masters with which the Slave is allowed to synchronize, do
the following:
1. Identify eight or fewer Master stations with which the
Slave is allowed to synchronize by selecting Master
.
2. Enter the channel and subchannel pairs that you set
for Channel and Subchannel, as follows:
Channel 1
Subchannel 1
Setting* Description
Channel Channel the Master WLIF radio is using
(default is 1).
Subchannel Subchannel the Master WLIF radio is
using (default is 1).
* Channel and Subchannel are discussed on page 4-62.
