Step 4: Set TX Filters
Support for both NNL and IP stations is required. This
example assumes DIX Ethernet is supported, but 802.3 and
SNAP are not required. NNL is enabled by the default
settings. Following is the [Frame Types] screen:
Action
Scope
DIX-IP-Other Protocols
Following is the [SubTypes 1] screen:
Action
SubType
Value
NNL
87 5b
The default settings for IP protocols enable ARP and ICMP.
TCP and UDP are disabled by default. Applications
running over TCP or UDP can be enabled by changing the
DIX TCP and DIX UDP ports to pass all frames. Following
is the [Frame Types] screen:
Action
Scope
DIX-IP-TCP Ports
DIX-IP-UDP Ports
