APPENDIX D
"
S-UHF Specifications and Antennas
6710 Access Point User’s Guide D-3
Wireless Hops
Because of the low data rate, wireless hops are not
supported for S-UHF systems.
Antenna Connector
The S-UHF antenna uses a standard BNC connector.
Whip Antennas
For S-UHF, the standard whip antenna is the primary
antenna. Its part number is 805-511-001.
A cabled external antenna is required in cases where the
access point and antenna cannot be installed at the same
location. Antennas should be installed to maximize
separation distance from metal obstructions. The
recommended minimum separation distance is 19 feet (6
meters).
The following chart lists cabled external whip antennas.
Length Part Number
5 feet 203-449-002
18 feet 203-449-003
36 feet 203-449-001
50 feet 203-449-004
75 feet 203-449-005
100 feet 203-449-006
