APPENDIX E
"
OWL/IP
E-18
6710 Access Point User’s Guide
Alternatively, if a limited set of known applications is to be
supported, filters may be set to selectively pass listed Port
numbers. Following is the [Frame Types] screen:
Action
Scope
DIX-IP-TCP Ports
DIX-IP-UDP Ports
For example, to support FTP (data and control) and Telnet,
enable protocol ports 20, 21, and 23, respectively.
The above IP port numbers are specified as decimal values.
These can be input directly by following the entry with a
decimal point; for example, “20.” Values are displayed in
the table as hexadecimal values: 14, 15, and 17.
Following is the [SubTypes 1] screen:
Action
SubType
Value
DIX-ARP
08 06
SNAP-ARP
08 06
802.2-IPX-RIP
04 51
802.2-IPX-SAP
04 53
NNL
87 5b
NETBIOS
f0 f0
1
00 01
2
00 14
3
00 15
4
00 17
.
.
16
00 00
