APPENDIX D
"
S-UHF Specifications and Antennas
D-8 6710 Access Point User’s Guide
" NOTE: A site survey is required for this type of installation.
Figure D-2
Frequency Reuse
Access Point A Access Point B
--105 dBm
In this type of installation, you can install access points on
the same frequency. Each access point can sustain the
single frequency wireless station population and
transaction rate. The guideline for frequency reuse is:
The signal level produced by access point “A” must be
less than --105 dBm at the required coverage limit of
access point “B.”
Increasing System Throughput
To increase the wireless station population or system
transaction rate, you can overlap access point coverage
areas and use multiple frequencies. The system design
allows up to four frequencies, 100 stations, and three
transactions per second. Large wireless station populations
or transaction rates require use of one of the high speed RF
media.
