In example 1, [Frame Types] is set as follows:
Action Scope
DIX-IP-TCP Ports
DIX-IP-UDP Ports
DIX-IP-Other Protocols
DIX-IPX Sockets
DIX-Other EtherTypes
SNAP-IP-TCP Ports
SNAP-IP-UDP Ports
SNAP-IP-Other Protocols
SNAP-IPX Sockets
SNAP-Other EtherTypes
802.3-IPX Sockets
802.2-IPX Sockets
802.2-Other SAPs
Example 2
Access points 2 and 4 in Figure 4-3 service IP wireless
stations as well as wired IP and IPX hosts on the secondary
LAN. These access points have an additional requirement
to pass IPX traffic.
The IPX router in this network periodically sends IPX-RIP
(Routing Information Protocol) frames for coordinating with
other routers. These do not need to be forwarded to the
secondary LAN because the secondary LAN does not
contain a router.
To filter the RIP frames, it is necessary to use the
[SubTypes 1] configurations. The example sets filters for
three different cases: DIX, 802.2, or 802.3 SNAP frames.
In many actual networks, only one of these would be
required, since all stations would be configured for one of
the three options.
