# Allow the local AS number to appear in the AS-PATH attribute of the routes received.
[PE3-bgp-af-vpnv4] peer 2.2.2.9 allow-as-loop 2
[PE3-bgp-af-vpnv4] quit
[PE3-bgp] quit
# Configure CE 1.
[CE1] bgp 200
[CE1-bgp] peer 1.1.1.9 as-number 200
[CE1-bgp] peer 1.1.1.9 connect-interface loopback 0
[CE1-bgp] ipv4-family vpnv4
[CE1-bgp-af-vpnv4] peer 1.1.1.9 enable
[CE1-bgp-af-vpnv4] undo policy vpn-target
[CE1-bgp-af-vpnv4] quit
[CE1-bgp] quit
NOTE:
Configurations on PE 4 and CE 2 are similar to those on PE 3 and CE 1 respectively, and are thus omitted
here.
7. Verify the configurations.
After completing all the configurations, execute the display ip routing-table command on PE 1 and
PE 2 to verify that the public routing tables contain only routes on the service provider network. The
following takes PE 1 for illustration.
[PE1] display ip routing-table
Routing Tables: Public
Destinations : 7 Routes : 7
Destination/Mask Proto Pre Cost NextHop Interface
3.3.3.9/32 Direct 0 0 127.0.0.1 InLoop0
4.4.4.9/32 ISIS 15 10 30.1.1.2 POS5/1/2
30.1.1.0/24 Direct 0 0 30.1.1.1 POS5/1/2
30.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0
30.1.1.2/32 Direct 0 0 30.1.1.2 POS5/1/2
127.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0
127.0.0.1/32 Direct 0 0 127.0.0.1 InLoop0
Execute the display ip routing-table vpn-instance command on PE 1 and PE 2 to verify that the VPN
routing tables contain sub-VPN routes. The following takes PE 1 for illustration.
[PE1] display ip routing-table vpn-instance vpn1
Routing Tables: vpn1
Destinations : 9 Routes : 9
Destination/Mask Proto Pre Cost NextHop Interface
11.1.1.0/24 Direct 0 0 11.1.1.1 POS5/1/1
11.1.1.1/32 Direct 0 0 127.0.0.1 InLoop0
11.1.1.2/32 Direct 0 0 11.1.1.2 POS5/1/1
100.1.1.0/24 BGP 255 0 11.1.1.1 NULL0
110.1.1.0/24 BGP 255 0 11.1.1.1 NULL0
