COM Objects Reference
DWDM Passive Component Test System
393
NotchResult Object
NotchResult Object
NotchResult Object
Description
This object acts as a repository that contains the results of the
analysis of a channel for which the mask type has been
identified as a notch.
NotchResult objects constitute the items of the array returned
by the PowerLevels property from the Notch object.
Note
You can access a NotchResult object (an individual item of the
array) with the help of an index value.
object.NotchResults (Index)
Index: Required. An Integer value that uniquely identifies a
member of the PowerLevels array.
A NotchResult object contains many results of analysis based on
one of the power levels defined through the PowerLevels
property. This object allows to obtain the bandwidth, central
wavelength, ORL and PDL results for the current channel at the
current power level.
NotchResult object has these properties:
³
Bandwidth
³
BwLowerBound
³
BwUpperBound
³
CentralWavelength
³
OrlBw
³
OrlCw
³
PdlBw
³
PdlCw
³
PowerLevel
