EXFO IQS-12004B DWDM Passive Component Test System for IQS-500 - Manual (Page 210)

Automating or Remotely Controlling the System
198 IQS-12004B
SCPI Error Messages
48 Invalid power meter value (over range).
49 The sweep cannot be performed. The laser source is
not turned on.
52 Not available in simulator mode.
53 Number of acquisition points must be between 1 and
32 000.
513 Invalid parameter.
514 Wrong function was called.
515 Invalid number of channels.
516 No module is initialized.
517 Unable to open the log file.
518 Error when closing the log file.
532 System error.
533 GPIB board has to be controller in charge (CIC) to
function properly.
534 No listeners on the GPIB.
535 GPIB board not correctly addressed.
536 Invalid argument when the function is called.
537 GPIB board is not CIC, as required.
538 I/O operation aborted (Time Out).
539 GPIB board not installed.
540 Direct memory access (DMA) error.
542 Asynchronous I/O in progress.
543 Cannot operate.
544 File system error.
Error Number Description
