Ranges, Configuration – EXFO IQS-12004B DWDM Passive Component Test System for IQS-500 User Manual
Page 111
Interpreting the DWDM Passive Component Test System Results
DWDM Passive Component Test System
99
Viewing the Results Graph
Ranges
To define the graph scaling and visible ranges, select the Ranges tab. Click
Use Default Ranges to return to the default values shown below at any
time.
Note: The default wavelength range is determined by the Analysis Range selected
in the Setup window.
Configuration
To save the parameters defined for ranges, curves, and graph options,
select the Configuration tab.
