5-20
Ultra-High-Speed Flash
Microcontroller User’s Guide
Table 5-2. Instruction Speed Summary
INSTRUCTION CATEGORY
SPEED
ADVANTAGE
QUANTITY
4.0 2
4.8 1
5.3 1
6.0 12
8.0 5
12.0 27
Total instructions: 1 byte
24.0 1
4.0 1
6.0 27
8.0 5
Total instructions: 2 byte
12.0 13
4.8 3
6.0 5 Total instructions: 3 byte
8.0 8
Average across all instructions 8.5 111
OPCODE CATEGORY
SPEED
ADVANTAGE
QUANTITY
4.0 4
4.8 1
5.3 1
6.0 35
8.0 5
12.0 93
Total opcodes: 1 byte
24.0 1
4.0 1
6.0 42
8.0 5
Total opcodes: 2 byte
12.0 43
4.8 4
6.0 12 Total opcodes: 3 byte
8.0 8
Average across all opcodes 9.4 255
