External Reset

If the RST input is asserted to logic 1, the device is forced into a reset state. An external reset is accomplished by holding the RST pin

high at least four clock cycles while the oscillator is running. Once the reset state is invoked, it is maintained as long as RST is assert-

ed at logic 1. When the RST is removed, the processor exits the reset state within four clock cycles and begins execution at address

0000h.

If an RST is applied while the processor is in the stop mode, the RST causes the oscillator to begin running and forces the program

counter to 0000h. The reset delay is 65,536 clock cycles to allow the oscillator to stabilize.

The RST pin is a bidirectional I/O. If a reset is caused by a power fail reset, a watchdog timer reset, an oscillator fail detect reset, or

an internal system reset, a positive output level is also generated at the RST pin. This reset level is asserted as long as an internal reset

is asserted. The drive capability of this I/O port may be insufficient if the RST pin is connected to a RC reset circuit. Connecting the

RST pin to a capacitor would not affect the internal reset condition.

Determining The Cause Of a Reset

During the debugging process, it might be necessary to isolate the cause of a device reset. Because resets are initiated by a limited

number of sources, it is relatively easy to determine their source by interrogating the flag bits associated with the reset sources. The

table below lists the reset sources and flag bits. Although no flag bits are associated with the internal system reset generated by issu-

ing a system reset or complement bank-select flash command, it is unlikely that these would occur unintentionally, given that the flash

command bits (FCNTL.3-0) require a timed-access write.

Table 8-1. Reset Source Flag Associations

RESET SOURCE

FLAG BIT

Power-on reset

POR – WDCON.6

Watchdog reset

WTRF – WDCON.2

Oscillator fail-detect reset

OFDF – PCON.5

Internal system reset

None

External reset

None

Ultra-High-Speed Flash
Microcontroller User’s Guide

Maxim Integrated
