11-4
Ultra-High-Speed Flash
Microcontroller User’s Guide
BIT NAMES DESCRIPTION REGISTER LOCATION BIT POSITIONS
GATE Gate control enable for INT0 pin TMOD – 89h TMOD.3
C/T Counter/timer select TMOD – 89h TMOD.2
M1, M0 Timer mode select bits TMOD – 89h TMOD.1,0
TF0 Timer overflow flag TCON – 88h TCON.5
TR0 Timer run control TCON – 88h TCON.4
T0M Input clock select (/4) CKCON – 8Eh CKCON.3
T0MH Input clock high-speed select (/1) CKMOD – 96h CKMOD.3
Timer LSB TL0 – 8Ah
T
IM
ER
0
Timer MSB TH0 – 8Ch
GATE Gate control enable for INT1 pin TMOD – 89h TMOD.7
C/T Counter/timer select TMOD – 89h TMOD.6
M1, M0 Timer mode select bits TMOD – 89h TMOD.5,4
TF1 Timer overflow flag TCON – 88h TCON.7
TR1 Timer run control TCON – 88h TCON.6
T1M Input clock select (/4) CKCON – 8Eh CKCON.4
T1MH Input clock high-speed select (/1) CKMOD – 96h CKMOD.4
Timer LSB TL1 – 8Bh
T
IM
ER
1
Timer MSB TH1 – 8Dh
TF2 Timer overflow flag T2CON – C8h T2CON.7
EXF2 Timer external flag T2CON – C8h T2CON.6
RCLK Timer 2 receive serial clock enable T2CON – C8h T2CON.5
TCLK Timer 2 transmit serial clock enable T2CON – C8h T2CON.4
EXEN2 External enable for T2EX pin T2CON – C8h T2CON.3
TR2 Timer run control T2CON – C8h T2CON.2
C/T2 Counter/timer select T2CON – C8h T2CON.1
CP/RL2 Capture/reload select T2CON – C8h T2CON.0
T2OE Output enable for T2 pin T2MOD – C9h T2MOD.1
DCEN Down count enable T2MOD – C9h T2MOD.0
T2M Input clock select (/4) CKCON – 8Eh CKCON.5
T2MH Input clock high-speed select (/1) CKMOD – 96h CKMOD.5
Timer LSB TL2 – CCh
Timer MSB TH2 – CDh
Timer capture LSB RCAP2L – CAh
T
IM
ER
2
Timer capture MSB RCAP2H – CBh
Table 11-1. Programmable Timers
