Ultra-High-Speed Flash
Microcontroller User’s Guide
PIS2-0
Bit 7, 6, 5
Priority Interrupt Status Bits 2-0. These bits indicate the level of interrupt that is currently being
serviced. (Interrupt levels 0-3 are associated with interrupt sources using the MP,LP bits found in
the IP1 and IP0 SFRS.)
Bit 4
SPTA1
Bit 3
SPRA1
Bit 2
SPTA0
Bit 1
SPRA0
Bit 0
This bit is reserved and reads a logic 1.
Serial Port 1 Transmit Activity Monitor. When set, this bit indicates that data is currently being
transmitted by serial port 1. It is cleared when the internal hardware sets the TI_1 bit. Do not alter
the clock divide control bits (PMR.7-6) while this bit is set or serial port data can be lost.
Serial Port 1 Receive Activity Monitor. When set, this bit indicates that data is currently being
received by serial port 1. It is cleared when the internal hardware sets the RI_1 bit. Do not alter the
clock divide control bits (PMR.7-6) while this bit is set or serial port data can be lost.
Serial Port 0 Transmit Activity Monitor. When set, this bit indicates that data is currently being
transmitted by serial port 0. It is cleared when the internal hardware sets the TI_1 bit. Do not alter
the clock divide control bits (PMR.7-6) while this bit is set or serial port data can be lost.
Serial Port 0 Receive Activity Monitor. When set, this bit indicates that data is currently being
received by serial port 0. It is cleared when the internal hardware sets the RI_1 bit. Do not alter the
clock divide control bits (PMR.7-6) while this bit is set or serial port data can be lost.
PIS2-0
INTERRUPT PRIORITY LEVEL
000
No interrupt in progress
001
Level 0 interrupt in progress
010
Level 1 interrupt in progress
011
Level 2 interrupt in progress
100
Level 3 interrupt in progress
101
Power-fail warning interrupt in progress
TA.7–0
Bits 7–0
Timed Access. Correctly accessing this register permits modification of timed access protected
bits. Write AAh to this register first, followed within 3 cycles by writing 55h. Timed access protected
bits can then be modified for a period of 3 cycles measured from the writing of the 55h.
W = Unrestricted write, -n = Value after reset
Timed Access Register (TA)
7
6
5
4
3
2
1
0
SFR C7h
TA.7
TA.6
TA.5
TA.4
TA.3
TA.2
TA.1
TA.0
W-1
W-1
W-1
W-1
W-1
W-1
W-1
W-1
R = Unrestricted read, W = Unrestricted write, -n = Value after reset
Status Register (STATUS)
7
6
5
4
3
2
1
0
SFR C5
PIS2
PIS1
PIS0
—
SPTA1
SPRA1
SPTA0
SPRA0
R-0
R-0
R-0
R-1
R-0
R-0
R-0
R-0
