Cub Cadet 7000 Series - Manual (Page 38)

7264 Compact Tractor
2.6. Pry up on the rock shaft, using the hex cap
screw head as the pivot point, with the pry bar.
NOTE: This step allows the transmission cover
to be lifted away from the transmission assem-
bly.
2.7. Remove the long hex cap screw.
2.8. Remove the transmission housing cover from
the transmission housing using both sides of the
rock shaft as lifting points.
NOTE: Make certain the rock shaft does not
slide out of the transmission housing cover.
3. MOTOR SHAFT SPACER:
3.1. Secure the motor shaft spacer in position using a
shop towel. See Figure 3.1.
NOTE: The applied tension to the motor shaft
spacer will keep the remaining motor shaft com-
ponents from sliding out of the transmission
housing.
4. PTO SHIELD:
4.1. Remove all four hex cap screws securing the
PTO shield to the rear housing cover using a
1/2” socket. See Figure 4.1.
NOTE: Loctite™ the threads and torque them
between 160 and 200 In. Lbs. during assembly.
4.2. Remove the PTO shield.
5. HYDRAULIC OIL DIPSTICK:
5.1. Remove the hydraulic oil dipstick. See Figure
5.1.
Figure 3.1
Shop Towel
Motor Shaft Spacer
Figure 4.1
Hex Screws
Hex Screws
PTO Shield
Rear
Housing
Cover
Figure 5.1
Hydraulic Oil Dipstick
6 - 44
