7264 Compact Tractor
16.13. Remove the wiring harness connector, red wire,
from the fuel solenoid connector. See Figure
16.13.
16.14. Remove the wiring harness connector, orange
wire, from the oil pressure switch. See Figure
16.14.
16.15. Remove the hex cap screw securing the ground
wire terminals, thick black wires, and star
washer to the right engine bracket and engine
block. See Figure 16.15.
NOTE: The hex cap screw securing the ground
wire terminals is the first from the front of the
engine. Also, make certain the wire is positioned
correctly during installation, and the star washer
is between the terminals and the frame.
17. DRIVE SHAFT:
17.1. Mark the drive shaft halves where they come
together. See Figure 17.1.
Figure 16.13
Harness
Connector
Red Wire
Fuel
Solenoid
Connector
Figure 16.14
Harness
Connector
Orange Wire
Figure 16.15
Hex Cap Screw
Black
Ground Wires
Figure 17.1
Mark Drive Shaft Halves
