LTX Tractors
66
Linkage: pedal shaft
Description: The Clutch/brake pedal and the drive control
pedal operate on two concentric shafts.
• The clutch/brake shaft runs the full width of the
tractor.
• The drive control shaft is tubular, and pivots on
the clutch/brake shaft.
• Each shaft has a toothed latch plate. The latch
plates are next to each other.
• The cruise control/park brake lever operates a
common pawl that engages the latch plate of
whichever pedal is applied. See Figure 5.20.
• A travel limit pin passes through curved slots in
both of the latch plates. The pin is blocked into
place by the fenders. See Figure 5.21.
Figure 5.20
Cruise / park
pawl
Clutch/brake
latch plate
Drive (cruise control) latch plate
Figure 5.21
Travel limit pin
