LTX Tractors
140
Transmission Specifcations
Specification U.S. Metric
Pinion end play 0.010”-0.015” 0.25-0.38mm
Pinion run-out 0.002”-0.010” 0.05-0.25mm
Pinion backlash 0.006”-0.014” 0.15-0.36mm
Differential rivet.-to-gear clearance 0.030” minimum 0.762mm
Axle end-play 0.010”-0.08” 0.25-2.0
Amount of Durina grease,
2 10 oz. tubes (P/N: 737-0148) 20 fl.oz 0.59 liters
Brake clearance 0.010”-0.015” 0.25-0.38mm
Drive System Torque Specs.
Fastener Torque in-lb. Torque N-m
Seat bolt 60-80 17-20
Lug nut 350-500 41-57
Wheel bolt 160-190 18-22
Crankshaft bolt 450-600 51-68
Tq. bracket bolt 175-250 20-28
Axle T-bolt nuts 150-180 17-20
Tensioner bracket 150-180 17-20
Pedal shaft straps 150-180 17-20
Belt keeper nut /bolt 150-180 17-20
Idler pulley bolt 150-180 17-20
Brake yoke bolts 90-135 10-15
Input pulley nut 300-400 34-45
Housing screws 90-135 10-15
Detent screw 160-200 18-23
V.S. pulley bolt 150-180 17-20
V.S. bearing cover 90-135 10-15
Make-up pulley pivot bolt 175-250 20-28
