LTX Tractors
50
Dash Panel
The dash panel may be removed to provide easier
access to the cruise-control and drive system linkages, or
to replace the dash or dash support brackets.
1. Remove the fenders.
2. Remove the steering wheel:
2a. Remove the cover from the center of the
steering wheel. See Figure 4.36.
NOTE: The cover can be released by prying-in on
the lock-tabs on the under-side of the steer-
ing wheel. See Figure 4.37.
2b. Remove the bolt that holds the steering wheel
to the steering shaft using a 1/2” wrench.
2c. Lift the steering wheel off of the shaft.
Figure 4.36
Figure 4.37
! CAUTION ! CAUTION
The following steps involve working with gasoline. Gasoline is flammable, and steps should be
taken to avoid fire hazard;
• Work in a well-ventilated area.
• Allow the engine to cool fully before starting work on the tractor.
• Eliminate any sources of possible ignition from the work area, including but not limited to:
heat sources, open flame, potential sparks.
• Clean-up any spilled fuel quickly and properly, disposing of cleaning materials in a way that
will not produce a further fire hazard.
• Hold any drained fuel in an approved and safe container.
