Cub Cadet SLTX1000 Series User Manual
Page 217
Cutting Decks And Lift Shaft
211
• For a 42” timed “R” deck, See Figure 8.19.
• For a 42” staggered “S” deck. See Figure 8.20.
• For a 46” “H” deck, See Figure 8.21.
Figure 8.19
PTO belt
Timing belt
Figure 8.20
Figure 8.21
