CVT DRIVE AND BRAKE SYSTEM

105

14.

Disconnect the cobra-head rod from the pedal shaft
tie plate. See Figure 6.28.

• Slip the tie plate off of the cobra head rod.

• Push the hex bushing out of the big end of the

pedal shaft tie plate.

• The hex bushing can be snapped-off of the brake

pedal shaft.

15.

Once the cobra-head rod is loose, the drive control
pedal shaft can be rotated and slipped off of the
brake pedal shaft. See Figure 6.29.

16.

Inspect the pedal shaft components individually.
Replace any parts that are worn or damaged.

• The plastic bushings that fit between the two pedal

shafts should be replaced any time they are
removed. Lubricate them with a dry PTFE or
graphite-based lubricant on assembly. NOT
grease.

• Replace the push cap and all removed cotter pins

with new parts.

17.

Install the pedal shaft assembly by reversing the
steps used to remove it, then install the fenders.

NOTE: The pedal shaft support straps are two different

sizes. The smaller strap holds-up the left (brake
pedal) end of the pedal shaft assembly. The larger
strap holds-up the right (drive control pedal) end of
the pedal shaft assembly. See Figure 6.30.

Figure 6.28

Cobra-head

Tie plate

Hex bushing

Figure 6.29

Drive control pedal shaft

Cobra head

Bushings

Brake pedal
shaft

Figure 6.30

Left side strap Right side strap
