Body Panels
49
NOTE: The handle assemblies can be removed from the
rear fenders using a 3/8” wrench, from beneath the
fender. See Figure 4.34.
NOTE: With the handle assembly removed, the steel rein-
forcement plate can be unbolted from the top side
of the fender using a 3/8” wrench. See Figure 4.35.
Figure 4.34
Screws that hold
the handle assembly
Steel reinforcement plate
Figure 4.35
Reinforcement plate
mounting screws
