LTX Tractors
48
6d. Remove the nuts and bolts that hold the front
edge of each fender to the frame outriggers
using a pair of 7/16” wrenches.
See Figure 4.32.
6e. Carefully lift the fender assembly off of the
tractor.
NOTE: On tractors equipped with a Kohler single
cylinder engine, the front of the fender
mounts to the outrigger using a rubber bush-
ing and steel spacer. See Figure 4.33.
Figure 4.32
Nut, bolt, and washer
Figure 4.33
Rubber
bushing
Steel spacer
