LTX Tractors
32
8. Inspect the EPS motor gasket. If it is damaged,
replace it.
NOTE: Do not use a gasket sealant/adhesive on the
EPS motor gasket.
9. Remove the sun gear from the EPS motor.
10. Install the sun gear into the planetary gear set.
11. Install the EPS motor.
NOTE: While installing the EPS motor, align the
motor pigtail with the EPS motor harness.
12. Install the EPS assembly in the tractor by following
the procedures described in the EPS removal sec-
tion of this chapter, in reverse order.
13. Test run the tractor in a safe area before returning it
to service.
NOTE: Do not put a tractor into service with any
safety or control features that are not work-
ing properly.
Figure 3B.14
Sun gear
Figure 3B.15
EPS motor pigtail
Harness
