Ordering Code Installation and Operation Handbook
A-2 2416 Controller
Part 1A: Hardware coding
Model
number
Function Supply
voltage
Module 1
2416 CC VH LH
Continue next page
►
Function
CC Controller/8-seg
Programmer
CP Single 16-segment
Programmer
P4 Four Program 16-
segment
VC Valve positioner (VP)
/8 segment Prog.
VP VP/Single Prog. 16-
segment
V4 VP/Four Program.
16-segment
Supply voltage
VH 85 to 264Vac
VL 20 to 29Vac/dc
Module 1
XX None
Relay: 2-pin
R2 Fitted unconfigured
RH PID heating
RU Valve raise output
Or Alarm 1: select from table A
Logic non-isolated
L2 Fitted unconfigured
LH PID heating
M1 PDSIO mode 1 (1)
M2 PDSIO mode 2 (1)
Triac
T2 Fitted unconfigured
TH PID heating
TU Valve raise output
DC control non-isolated
D2 Unconfigured
H1 0-20mA
heating
H2 4-20mA heating
H3 0-5Vdc heating
H4 1-5Vdc heating
H5 0-10Vdc heating
Table A : Alarm relay
functions
FH High alarm
FL Low alarm
DB Deviation band
DL Low dev. alarm
DH High dev alarm
