Figure 3.2, Show – Rockwell Automation 2098-IPD-xxx Ultra5000 Intelligent Positioning Drives Installation Manual User Manual
Page 63

Publication 2098-IN001E-EN-P — April 2002
Connecting Your Ultra5000
3-3
2. Relocate the digital I/O power jumpers on the regulator board.
shows the location of the J12 and J13 jumpers. Move
both jumpers from the EXT position to the INT position.
Note: The fuse (F1) protects the circuit only when the internal
power is selected.
3. Reinstall the cover.
Figure 3.1
Removal of Cover Panel from Ultra5000 Drive
Figure 3.2
Jumper Settings for External or Internal Digital I/O Power
Mating
Connectors
6-32 x 1/4” Screws
J12 and J13 position for
EXT 24V dc (factory setting)
U99
U102
Y2
U82
U87
U90
U91
U92
U96
U98
U39
U42
U56
U19
RP204
S1
S2
SPARE
RP63
RP77
RP78
RP80
R200
R207
RP6
RP11
RP12
RP15
R131
R136
L24
R43
J11
J12
J13
J20
J21
J4A
L3
L6
L13
L14
L16
C191
C200
CN4
D1
E1
F1
J2
J6
C134
C152
C153
C110
C113
C49
C50
C50B
INT
EXT
X1
U84
U30
J12 and J13 position for
INT 24V dc (optional setting)
Fuse (F1) for INT 24V dc circuit.
