Publication 2098-IN001E-EN-P — April 2002
1-2 Installing Your Ultra5000
EMC Directive
This unit is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) using a technical construction
file and the following standards, in whole or in part:
• EN 50081-2 EMC - Emission Standard, Part 2 - Industrial
Environment
• EN 50082-2 EMC - Immunity Standard, Part 2 - Industrial
Environment
• EN 61800-3 - Adjustable Speed Electrical Power Drive Systems,
Part 3 - EMC Product Standard including specific test methods
The product described in this manual is intended for use in an
industrial environment.
To meet CE requirements, the following additions are required:
• Install a power line filter between the AC power source and the
drive input, as close to the drive as possible. ( Refer to AC Line
Filters on page C-3 .)
• Terminate the motor power cable shield to the chassis clamp
provided.
• To meet CE requirements, the following additions may also be
required:
– Run single-phase input wiring in conduit that is grounded to
the enclosure.
– Terminate the shields of the motor power cables and the
motor feedback cables to the enclosure at the point of entry.
Low Voltage Directive
These units are tested to meet Council Directive 73/23/EEC Low
Voltage Directive. The EN 60204-1 Safety of Machinery-Electrical
Equipment of Machines, Part 1-Specification for General Requirements
standard applies in whole or in part. Additionally, the standard
EN 50178 Electronic Equipment for use in Power Installations applies
in whole or in part.
Refer to Appendix B for interconnect information.
