Installing Your Ultra5000
Mounting Your Ultra5000
Drive
The procedures in this section assume you have prepared your panel
and understand how to bond your system. For installation instructions
regarding other equipment and accessories, refer to the instructions
that came with each of the accessories for their specific requirements.
To mount your Ultra5000 drive:
1. Layout the positions for the Ultra5000 and accessories in the
enclosure. Mounting hole dimensions for the Ultra5000 are shown
in Appendix A.
2. Attach the Ultra5000 to the cabinet, first using the upper mounting
slots of the drive and then the lower. The recommended mounting
hardware is M5 metric (1/4-20) or #10 MS bolts. Observe bonding
techniques as described in
.
2. Tighten all mounting fasteners.
ATTENTION
!
This product contains ESD (Electrostatic Discharge)
sensitive parts and assemblies. Follow static control
precautions when you install, test, service, or repair
this assembly.
Refer to Allen-Bradley publ
,
Guarding Against Electrostatic Damage or any other
applicable ESD Protection Handbook.
Failure to observe this precaution may result in
damage to the equipment.
