Page 34

Publication 2098-IN001E-EN-P — April 2002
2-8
Ultra5000 Connector Information
3 kW Ultra5000
(2098-IPD-030)
Use the figure below to locate the front panel connections on the
Ultra5000 230V drive (3 kW). Detailed descriptions of the digital
connections are provided on pages
through
connections are described below.
Figure 2.3
Ultra5000 Front Panel Connections
for 2098-IPD-030
The following tables list the power and shunt connections on the
terminal block (TB).
Refer to Wiring Power Connections on page 3-14
for additional information.
U
V
W
+
-
L1
L1
L2
L2
L1
L1
AUX
AUX
L2/N
L2/N
AUX
AUX
Motor
Motor
DC Bus
DC Bus
1
2
3
Internal
Internal
External
External
Shunt
Shunt
DC Bus
DC Bus
C
N
3
A
C
N
3
B
C
N
2
CN1A
CN1A
Status
Status
PWR
PWR
Node Address
Node Address
(00-63, PGM)
(00-63, PGM)
100-240 VAC
100-240 VAC
50/60 Hz
50/60 Hz
AC Input Power Terminals
Motor Power Terminals
DC Bus Terminals for
Shunt Resistor
Seven Segment
Status LED
Logic Power LED
CN3A 9-pin
Main Serial Port
Node Address
Selector Switches
CN3B 9-pin
Auxiliary Serial Port
DC Bus Terminals
CN2 15-pin
Motor Encoder
CN1A 28-pin
Digital I/O
CN1B 14-pin
Auxiliary Encoder
and Analog I/O
