Publication 2098-IN001E-EN-P — April 2002
Catalog Numbers and Accessories
C-7
Motor Feedback Cables
Applicable Drive(s)
Description
Catalog Number
All 2098-IPD-
xxx and
-HV
xxx
H, F and W-Series Motor Feedback Cable, non-flex, connector at both ends, right angle,
skewed
2090-UXNFBHF-K
xx
H, F and W-Series Motor Feedback Cable, non-flex, connector at both ends, right angle
2090-UXNFBHF-R
xx
H, F and W-Series Motor Feedback Cable, non-flex, connector at both ends, straight
2090-UXNFBHF-S
xx
H-Series Motor Feedback Cable, non-flex, connector at both ends, right angle
2090-UXNFBH-R
xx
1326AB-B
xxxx-M2L or -S2L Motor Feedback Cable, non-flex, connector at both ends,
straight
2090-UXNFBMP-S
xx
MP-Series Motor Feedback Cable, non-flex, connector at both ends, straight
2090-UXNFBMP-S
xx
N-Series Motor Feedback Cable, non-flex, connector at both ends, right angle, skewed
2090-UXNFBN23-K
xx
N-Series Motor Feedback Cable, non-flex, connector at both ends, right angle, skewed
2090-UXNFBN-K
xx
N-Series Motor Feedback Cable, non-flex, connector at both ends, right angle
2090-UXNFBN-R
xx
N-Series Motor Feedback Cable, non-flex, connector at both ends, straight
2090-UXNFBN-S
xx
Y-Series Motor Feedback Cable, non-flex, connector at both ends, straight
2090-UXNFBY-S
xx
H, F and W-Series Motor Feedback Cable, non-flex, motor connector to flying leads,
straight
2090-UXNFDHF-S
xx
H, F and W-Series Motor Feedback Cable, non-flex, motor connector to flying leads, right
angle
2090-UXNFDH-R
xx
1326AB-B
xxxx-M2L or -S2L Motor Feedback Cable, non-flex, motor connector to flying
leads, straight
2090-UXNFDMP-S
xx
MP-Series Motor Feedback Cable, non-flex, motor connector to flying leads, straight
2090-UXNFDMP-S
xx
N-Series Motor Feedback Cable, non-flex, motor connector to flying leads, right angle,
skewed
2090-UXNFDN23-K
xx
N-Series Motor Feedback Cable, non-flex, motor connector to flying leads, right angle
2090-UXNFDN-R
xx
N-Series Motor Feedback Cable, non-flex, motor feedback connector to flying leads,
straight
2090-UXNFDN-S
xx
Y-Series Motor Feedback Cable, non-flex, motor feedback connector to flying leads,
straight
2090-UXNFDY-S
xx
Drive Feedback Cable, non-flex, CN2 connector to flying leads, straight
2090-UXNFM-S
xx
