Publication 2098-IN001E-EN-P — April 2002
C-2 Catalog Numbers and Accessories
Ultra5000 Drives
Use the following table to identify Ultra5000 240V drives with ratings
of 500W, 1 kW, and 2 kW.
Use the following table to identify Ultra5000 240V drives with ratings
of 3 kW, 7.5 kW, and 15 kW.
Use the following table to identify Ultra5000 460V drives with ratings
of 3 kW, 5 KW, 10 kW, 15 kW, and 22 kW.
Ultraware Software
The Ultra5000 drives are configured using Ultraware. Ultraware is a
Windows
®
based application that allows drive configuration to be
done off-line and saved to disk.
Description Catalog Number
Ultra5000 Intelligent Positioning Drives 2098-IPD-005,
2098-IPD-010,
2098-IPD-020
Ultra5000 Intelligent Positioning Drives with DeviceNet 2098-IPD-005-DN,
2098-IPD-010-DN,
2098-IPD-020-DN
Description Catalog Number
Ultra5000 Intelligent Positioning Drives 2098-IPD-030,
2098-IPD-075,
2098-IPD-150
Ultra5000 Intelligent Positioning Drives with DeviceNet 2098-IPD-030-DN,
2098-IPD-075-DN,
2098-IPD-150-DN
Description Catalog Number
Ultra5000 Intelligent Positioning Drives 2098-IPD-HV030,
2098-IPD-HV050,
2098-IPD-HV100,
2098-IPD-HV150,
2098-IPD-HV220
Ultra5000 Intelligent Positioning Drives with DeviceNet 2098-IPD-HV030-DN,
2098-IPD-HV050-DN,
2098-IPD-HV100-DN,
2098-IPD-HV150-DN,
2098-IPD-HV220-DN
Description Catalog Number
Ultraware Software 2098-UWCPRG
