Publication 2098-IN001E-EN-P — April 2002
Interconnect Diagrams B-23
Ultra5000 Shunt Module
Information
This section directs you to information sources for wiring an active or
passive shunt module to your Ultra5000 drive.
300 Watt Active Shunt Module
Use the 2090-UCSR-A300 active shunt module with the Ultra5000
(2098-IPD-005-xx, -010-xx, and -020-xx) drives.
Use shielded, high temperature 75° C (167° F), 600V, 2.5-4.0 mm
2
(12-14 AWG), 3.05 m (10 ft) maximum, copper wire. Follow one of the
methods given below to reduce the effects of EMI noise:
• Install wires using twisted pairs (two turns per foot minimum), as
shown in the figure above. Keep unshielded wires as short as
possible.
• Use shielded, twisted cable (ground shield at shunt and drive).
• Use shielded metal conduit (ground conduit at shunt and drive).
For more information, refer to the 300 Watt Active Shunt Regulator
Installation Instructions , publication 2090-IN002 .
200 Watt Passive Shunt Module
A 2090-UCSR-P200 passive shunt module can be used with the 230V
Ultra5000 drive (2098-IPD-030-xx).
Use shielded, high temperature 75° C (167° F), 600V, 2.5 mm
2
(14
AWG), 3.05 m (10 ft) maximum, copper wire. Follow one of the
methods given below to reduce the effects of EMI noise:
• Install wires using twisted pairs (two turns per foot minimum), as
shown in the figure above. Keep unshielded wires as short as
possible.
• Use shielded, twisted cable (ground shield at shunt and drive).
• Use shielded metal conduit (ground conduit at shunt and drive).
For more information, refer to the 200 Watt Passive Shunt Module
Installation Instructions , publication 2090-IN003 .
