C-4
Catalog Numbers and Accessories
External Shunt Kits
External shunts are available for use with Ultra5000 drives.
to Related Documentation on page P-3
to locate Installation
Instructions for these shunts.
Use the following tables to identify external shunt kits available for
Ultra5000 drives.
Refer to Ultra5000 Shunt Module Information on
for basic wiring guidelines.
If your drive is:
You may use this shunt
Catalog Number
2098-IPD-005, -005-DN
with 300 Watt Active Shunt
Ferrites
2090-UCSR-A300
1
2098-IPD-010, -010-DN
2098-IPD-020, -020-DN
2098-IPD-030, -030-DN
200 Watt Passive Shunt Module 2090-UCSR-P200
2098-IPD-075, -075-DN
2090-UCSR-P900
2098-IPD-150, -150-DN
2098-IPD-HV030, -HV030-DN
2098-IPD-HV050, -HV050-DN
900 Watt 2090 Passive Shunt
Module
2
2098-IPD-HV100, -HV100-DN
900 Watt 2090 Passive Shunt
Module
2
2098-IPD-HV100, -HV100-DN
1800 Watt 2090 Passive Shunt
Module
2
2098-IPD-HV150, -HV150-DN
900 Watt 2090 Passive Shunt
Module
2
2098-IPD-HV150, -HV150-DN
1800 Watt 2090 Passive Shunt
Module
2
2098-IPD-HV220, -HV220-DN
3600 Watt 2090 Passive Shunt
Module
2
1
A 300W Active Shunt may be labelled with the obsolete Catalog Number 1398-SR3AF.
2
Refer to 2090 Series Passive Shunts on page C-5
for general specifications.
