Publication 2098-IN001E-EN-P — April 2002
B-24 Interconnect Diagrams
900 Watt Passive Shunt Module
Use the 2090-UCSR-P900 passive shunt module with the Ultra5000
drives (2098-IPD-075-xx or 2098-IPD-150-xx).
Use shielded, high temperature 75° C (167° F), 600V, 10 mm
2
(8
AWG), 3.05 m (10 ft) maximum, copper wire. Follow one of the
methods given below to reduce the effects of EMI noise:
• Install wires using twisted pairs (two turns per foot minimum), as
shown in the figure above. Keep unshielded wires as short as
possible.
• Use shielded, twisted cable (ground shield at shunt and drive).
• Use shielded metal conduit (ground conduit at shunt and drive).
For more information, refer to the 900 Watt Passive Shunt Module
Installation Instructions , publication 2090-IN001 .
2090 Passive Shunt Module
A 2090-SRxxx-xx passive shunt module can be used with 460V
Ultra5000 drives (2098-IPD-HV030-xx, -HV050-xx, -HV100-xx,
-HV150-xx, and -HV220-xx) operating with 460V or 230V input
power.
Note: Fusing on the 2090-SRxxx-xx passive shunt module must be
changed to accommodate 230V input power.
Use shielded, high temperature 105 ° C (221 ° F), 600V, 6 mm
2
(10
AWG), 3.05 m (10 ft) maximum, braided copper wire to connect
between the drive’s TB2-1 and TB2-3 external shunt terminals and the
shunt module terminals. Follow one of the methods below to reduce
the effects of EMI noise:
• Install wires using twisted pairs (two turns per foot minimum).
Keep unshielded wires as short as possible.
• Use shielded, twisted cable (ground shield at shunt and drive).
• Use shielded metal conduit (ground conduit at shunt and drive).
For more information, refer to the 2090 Series Passive Shunts
Installation Instructions , publication 2090-IN004 .
