Model 497.05 Hydraulic Control Panel
Models FlexTest® IIm/GT/SE Controller Hardware Introduction 31
Model 497.05 Hydraulic Control Panel
The hydraulic control panel provides the following functions.
• Control of up to four independent hydraulic service manifolds
• Hydraulic power supply control
• Interlock shutdown and latched indicators to show interlock status
• Programmable interlock station assignment
• Electrical power outputs to the hydraulic service manifolds and a 497.01
Analog Chassis
• Built-in Emergency Stop button and connections for a remote emergency
stop button
For details about configuring the hydraulic control panel for your system, see the
Series 497 Electronics Product Information manual (PN 100-036-577.)
Hydraulic Control Panel
Off L ow Hig h
Hydrauli c Power S upply
Emerg en c y St op
Ov er T emp
Low L ev el
Filte r Di rt y
Re se t
Inte rlo ck s
Hydraul ic
Control
497.05
m E mergency Stop HSM 1
In t er loc k 1
In t er loc k 2
Shu tdo wn
H yd rau lic Di sa bl ed
Off Pi lot Lo w Hig h
HS M 2
Inte rlock 1
Inte rlock 2
Shu t do w n
Hy dra ul ic Dis able d
Off Pi lot Lo w Hig h
HSM 3
Int erlo c k 1
Int erlo c k 2
Shu tdo wn
H yd rau lic Di sa bl ed
Off Pilo t Low High Off Pilo t Low High
HS M 4
Inte rlo ck 1
Inte rlo ck 2
Shu t do w n
Hy dra ul ic Dis ab le d
